Description
Coupling Accessories Machining Coupler Spare Parts Processing Connecting Parts Is Generally An Important Part Of Mechanical Processing Which Connects The Axis Of Motor And Rotating Equipment. Usually The Shaft Can’T Run Alone. To Make The Shaft Work Properly, The Coupling Must Be Used. Generally Speaking, The Manufacturer Of Motor And Rotating Equipment Is Not A Manufacturer, So The Size Of The Output Power Shaft On The Motor And The Connecting Spindle Of The Rotating Equipment Are Often Different, So A Different Diameter Coupling Is Needed As The Connecting Function. Even If The Diameters Of The Two Axles Are The Same, A Coaxial Coupling Is Needed To Connect The Two Axes In Order To Facilitate Replacement.
Of Course, A Reducer Is Often Installed Between The Motor And The Rotating Equipment. In This Way, Two Couplings Will Be Used. We Will Introduce The Reducer In More Detail In The Product Section Of The Reducer.
Coupling Belongs To The Category Of General Mechanical Parts, Which Is Used To Connect Two Shafts (Active And Driven Shafts) In Different Mechanisms And Rotate Them Together To Transfer Torque.
In High-Speed And Heavy-Load Power Transmission, Some Couplings Also Have The Functions Of Cushioning, Vibration Reduction And Improving The Dynamic Performance Of Shafting. The Coupling Consists Of Two Parts, Which Are Connected With The Driving Shaft And The Driven Shaft Respectively. Generally, The Power Machine Is Mostly Connected With The Working Machine By Means Of Coupling, Which Is The Most Commonly Used Connecting Part Of The Shafting Transmission Of Mechanical Products.
In The Late 20Th Century, The Domestic And Foreign Coupling Products Developed Rapidly. How To Select The Coupling Which Can Meet The Requirements Of The Machine From Various Types Of Coupling With Different Performances Is Always A Puzzling Problem For Most Designers.
Common Couplings Are As Follows:
Diaphragm Coupling,
Drum-Shaped Teeth Coupling,
Universal Coupling,
Safety Coupling,
Elastic Coupling
Serpentine Spring Coupling.
Main Uses
Coupling Is Widely Used. Generally, As Long As There Are Motors Or Reducers, It Is Necessary To Use Couplings. Large Couplings Are Widely Used In Metallurgical Machinery. Different Couplings Have Different Functions. The Functions Of Various Couplings Are As Follows:
1 , Connect The Prime Mover With The Shaft Of The Working Machine And Transfer The Torque.
2 , The Radial Axial And Angular Errors Caused By Manufacturing And Installation Of The Two Axes Can Be Compensated Appropriately.
3 , When The Safety Coupling Is Overloaded, The Coupling Slips Or The Pin Is Disconnected To Protect The Working Machinery.
4 , The Elastic Coupling Also Has The Functions Of Cushioning, Reducing Vibration And Improving The Dynamic Performance Of Shafting System.
